WS 500M Mobile Diesel Electric Hybrid Scrap Metal Shear Ideal for Scrap Yards and Metal Recycling Industry Applications

  • WS 500M Mobile Diesel Electric Hybrid Scrap Metal Shear Ideal for Scrap Yards and Metal Recycling Industry Applications
Lugar de origen Jiangsu, China
Nombre de la marca DLK
Certificación CE, ISO 9001
Número de modelo WS-500M
Cantidad de orden mínima 1 juego
Precio USD 98000-110000 per Set
Detalles de empaquetado Remolque de autotransporte, envoltura protectora para transporte marítimo
Tiempo de entrega 30-40 días hábiles
Condiciones de pago LC, T/T
Capacidad de la fuente 8 sistemas por mes
Datos del producto
Modelo WS-500M Tipo de energía Híbrido Eléctrico + Diésel
Fuerza de corte máxima 500 toneladas Longitud de la hoja 1400 milímetros
Altura del esquileo 300/420 milímetro Motor eléctrico 74 kilovatios 380V/3P
Motor diésel 120 CV Deutz Tiempo de funcionamiento del combustible 16 horas (tanque de 400L)
Movilidad Chasis de remolque integrado Control PLC + control remoto inalámbrico
Deja un mensaje
Descripción de producto
WS 500M Mobile Diesel Electric Hybrid Scrap Metal Shear Ideal for Scrap Yards and Metal Recycling Industry Applications
The WS-500M is a truly mobile scrap metal shear with a dual diesel-electric hybrid power system. Unlike conventional shears that require fixed power infrastructure, the WS-500M can operate on grid electricity when available or switch to its onboard diesel engine for remote locations without power access. The integrated trailer chassis allows rapid deployment between scrap yards.
Mobility & Power Flexibility
  • Dual Power Modes: 74 KW electric motor for grid operation + 120 HP diesel engine for off-grid sites
  • Seamless Power Switching: Automatic transfer between electric and diesel modes without interrupting operation
  • Integrated Trailer Chassis: Highway-towable design with standard fifth-wheel or ball hitch connection
  • No Foundation Required: Built-in hydraulic stabilizers deploy for level operation on any firm ground
  • Quick Deployment: Ready to operate within 30 minutes of arrival on site
  • Compact Container Style: 20-foot container footprint for easy transport by truck, rail, or ship
Applications
Perfect for mobile scrap processing services, temporary demolition sites, remote mining operations,base recycling, disaster cleanup operations, and multi-yard operators who move equipment between locations.
Technical Specifications
Parameter Specification
Model WS-500M
Power Type Hybrid (Electric + Diesel)
Max Cutting Force 500 Tons
Blade Length 1400 mm
Shear Height 300/420 mm
Cutting Speed 3-4 times/min
Processing Capacity 6-9 tons/hour
Electric Motor Power 74 KW (380V/3P 50Hz)
Diesel Engine Power 120 HP (Deutz Tier 3)
Fuel Tank Capacity 400 Liters (approx. 16 hours runtime)
Pump Type A4V250
Hydraulic System Pressure ≤ 26 MPa
Control System PLC + Wireless Remote Control
Cooling System Hydraulic Oil Cooler + Engine Radiator
Mobility Integrated Trailer Chassis with Stabilizers
Transport Dimensions 6200 x 2500 x 2800 mm
Machine Weight 28 Tons
Our Service
  • 24/7 global technical support via phone and remote access
  • One year comprehensive warranty on all components including engine
  • Worldwide spare parts delivery within 72 hours
  • On-site commissioning and operator training available
  • Custom diesel engine options (Deutz, Perkins) available
Contact us for a mobile demonstration at your location.
